Villa Pool Air Pump Accessories 50mm 80mm Thick Full Clear Acrylic Glass Sheet Panel

Ask Lasest Price
Brand Name :	AUPOOL
Model Number :	AUPOOL-infinitive pool
Supply Ability :	20000 Square Meter/Square Meters per Month
Price :	$273.00/square meters

Add to Cart

Product Details
Company Profile

Villa Pool Air Pump Accessories 50mm 80mm Thick Full Clear Acrylic Glass Sheet Panel

Clear Outdoor Acrylic Swimming Pool Made by AUPOOL

Acrylic Panel Specifications

PROPERTIES	VALUES	RULES
Density	1.19 g/cm3	ISO 1183-1:2012 Method A
Rockwell Hardness	112L	ISO 2039-2:1999
Tensile Modulus	3150MPa	EN ISO 527:2012
Tensile Strength	80.0MPa	EN ISO 527:2012
Tensile Strain at Break	3.2%	EN ISO 527-1:2012
Water Absorption	0.20%	ISO 62:2008 Method 1
Total Luminous Transmittance	93.4%	ISO 13468-1:1996
Vicat Softening Temperature	105℃	ISO 306:2013 Method B50
Light Ageing Test- UV Exposure	Grey scale: 5	ISO 4892-3:2016 Cycle 1
Mean Coefficient of Linear Thermal Expansion	72×10-6 K-1	ISO 11359-1:2014
Compressive Stress at Yield	129MPa	EN ISO 604:2003
Flexural Strength	120MPa	ISO 178:2013
Compressive Yield Strength	111MPa	ASTM D695-15
Compressive Modulus	3450MPa	ASTM D695-15
Shear Strength	59.7MPa	ASTM D732-17
Deflection Temperature under Load	100.2℃	ASTM D648-18 Method B
Modulus Elasticity	2810MPa	ASTM D695-15

Raw materials	100% virgin of Lucite MMA materials
Thickness	30-150mm one time casting, 150-950mm mm Multi-plate composite overlay
Color	Transparent(transparent 93%) of cast acrylic panel
MOQ	1 PCS acrylic panel/curve/tunnel/L shape acrylic panel
Below molding sizes are for your reference. Please note that: below size (molding size) ≠ panel net size
Size	Thickness	Size	Thickness
1300x2500mm	30-70mm	1350x2650mm	30-100mm
1450x2700mm	30-100mm	1600x2600mm	30-100mm
1650x3150mm	30-100mm	2200x3200mm	30-110mm
1650x3500mm	30-100mm	2750x4250mm	30-130mm
1800x5000mm	30-150mm	2100x5500mm	30-150mm
3000x6200mm	50-250mm	3000x6700mm	50-250mm
3000x8200mm	80-250mm	3000*8700mm	80-250mm
3000x11500mm	100-250mm	3700x8100mm	120-300mm
Generally, Our factory introducing the use of acrylic panels into architectural project such as oversize aquarium,outdoor swimming pool and water feature.

Products Description

Villa Pool Air Pump Accessories 50mm 80mm Thick Full Clear Acrylic Glass Sheet Panel

AUPOOL Infinity Pool

1. Professional Acrylic Swimming Pool Manufacturer

2. Dry constant temperature polymerization technology

3. Outdoor non-yellowing 30 years warranty

4. 93% high transparency

5. Easy installations & cleaning

6.More than 30 patents

Click Here to Contact Us, We Will Show You More Cases and Our New Products

Products and Applications

Rooftop transparent swimming pool at Khai Hoan Hotel, Vietnam (2016)

The rooftop swimming pool of Khai Hoan Hotel uses acrylic thick plates as the transparent swimming pool side and bottom plates,and adopts the world's leading water circulation system and constant temperature system, which has excellent weather resistance,safety and aesthetics.

Lingyun Pavilion suspended transparent swimming pool in Malaysia (2015)

The bottom of the swimming pool is made of three acrylic and reinforced concrete structures spliced together. The maximum size of a single acrylic panel window is 9m*6m, setting a world record for the world's largest single-panel acrylic suspended swimming pool (2015-2021).

Yingkou Bayu Bay Magic Hot Spring Park Hanging Transparent Swimming Pool (2020)

During the construction, the impact of the earthquake zone in the area was overcome, and the seismic resistance, safety and installation accuracy requirements of the plates all reached the international high standards; at the same time, the plates with excellent weather resistance were used, which was completely free from the extreme environment with a temperature difference of 60°C between inside and outside. The transparent part covers an area of 260 square meters, setting a world record for the largest suspended transparent swimming pool in the world at that time.

Sunshine One Hotel Haitang Bay Sanya suspended transparent swimming pool (2020)

The World's Largest Suspended Transparent Swimming Pool Sunshine One Hotel Haitang Bay SANYA

It is 63 meters long and 23 meters wide. The bottom plate is made of 280mm thick acrylic plate, and the side plate is made of 160mm thick acrylic plate. The transparent part covers an area of 820 square meters. World record for swimming pools.

Why Choose Us

Strong Production Capacity

7-15 days short production time, huge stock, large capacity.

Flat surface

Milling surface smooth on each panel

QC

Examine the interior of each Acrylic Panel under light

Dry thermostatic polymerization

Due to high technical barriers, only three companies in the world have mastered this process, which essentially solves the problem of acrylic turning yellow under light.

Flexible material

Flexural fracture resistance is very good, laboratory test bending deformation of 50% of the length dimension, hold for 1000 hours, no fracture marks

Strong impact resistance and safety

12 times that of tempered glass, 160 times that of ordinary glass, and will not automatically explode the board

How to order

Which one do you like, please let me know.

Acrylic in pool

1.Tell us the size

Tell us your swimming pool length,width and height,water level.It is better have design file.

2.Draft Design

By finite element analysis,we sure the thickness of acrylic,we draw design for you.

3.Production

We start production,cutting,bonding,bending,polishing,QC and packing,shipping to you

4.Installation

We provide you installation guide,our engineer can go to your side to do installation if necessary

Company Profile

AUPOOL is a professional manufacturer of transparent acrylic swimming pools. We are the only company in China that uses British
100% Lucite PMMA raw material and dry constant temperature polymerization process to make the acrylic board not yellow and crack
for 30 years outdoors. Welcome your consultation, we will provide you with private professional services 24 hours a day.

Certifications

Packing & Delivery

FAQ

Q1 : What kind of products do you sell?
A1: We are both a manufacturer and a trading company, we have our own factory and production lines to provide products with high quality and good price. We are One Stop Acrylic Swimming Pool Solution Provider.

Q2 : Which items do your factory produce?
A2 : Acrylic Thick Panel ,Prefab Acrylic Pool,Endless Pool Machine,Salt Chlorine Machine,Pool Cover,Swimming Pool Intelligent Control System

Q3:What is your terms of packing?

A3:

Use film to cover the surface of the swimming pools and bathtub；
Use EPE to wrap up swimming pools and bathtub;

Use foam to protect the frame of swimming pools and bathtub;
Wooden case could make sure strong protection.

Q4.:What is your terms of payment?

A4::T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q5. How about your delivery time?
A5: Generally, it will take 7 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q6. What is your sample policy?
A6: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q7:Do you test all your goods before delivery?
A7: Yes, we have 100% test before delivery

Q8:How to install?

A8:Customers can install it by themselves, and we provide free 24-hour online service. Our company arranges a professional team to install it. AUPOOL has a skilled and experienced acrylic professional installation team, who has participated in the design and construction of more than 1,000 domestic and foreign aquariums, acrylic infinity swimming pools, acrylic suspended swimming pools and other projects, with zero quality accidents so far. We use five layers of waterproofing for the swimming pool on the roof. So far, there has been no water leakage. If there is any water leakage in the same industry, they will seek our help to solve it.
